934-1035A

934-1035A

• Fits:
  • Ford Expedition from 2016 to 2025
  • Chevy Tahoe 2016 - 2025
  • Vehicle Specific Sub-frame Required
• Over all Dimensions:
  • Length: 30.1 inches.
  • Width: 40.0 inches.
  • Height: 17.5 inches.
    (Refer to engineering drawing for detailed measurements)
• Number of Drawer(s):
  • Three (3).
• Total Number of Divider(s):
  • Six (6).
• Twin Drawers, Internal Dimensions Per Drawer:
  • Length: 30.70 inches.
  • Width: 24.20 inches.
  • Height: 7.10 inches.
    (Refer to engineering drawing for detailed measurements)
• Single Drawer, Internal Dimensions Per Drawer:
  • Length: 32.10 inches.
  • Width: 10.50 inches.
  • Height: 7.10 inches.
    (Refer to engineering drawing for detailed measurements)
• Types of Lock(s):
  • Two (2) 400-1025 paddle latch SS stamped 501 key.
  • One (1) 400-0065 T-Handle.
• Types of Slides:
  • Two (3) Pairs of 32 inch Heavy Duty Slides.
• Finish:
  • Black Midnight Wrinkle paint.
• Material:
  • 11-gauge (0.09”) aluminum for strength and reliability
• Easy Installation:
  • Quick and simple installation with all necessary hardware included.
• Special Futures:
  • Rubber Lined Drawer Bottom.
  • Electronics Drawer (Internal 22.99”Lx36.25”Wx3.69”H).
• MUST BE PURCHASED SEPARATELY:
  • See D&R’s Cabinet and Partition selection for more custom solutions.
  • Sub-frames like (933-0238A - MK5, MK5.5 Chevrolet Tahoe Full Sub frame).
